Yamaha F150 Jet Drive Outboard Motor
$14,520.00
Yamaha F150 Jet Drive for sale, a 2.7L inline-four jet drive outboard at the propeller shaft, with EFI fuel induction, electric start, and direct drive gearing. Fits a 25″ transom. Backed by Yamaha’s limited warranty program.
Yamaha F150 Jet Drive for sale, a jet drive outboard engineered for shallow-water performance at the propeller shaft.
Yamaha F150 Jet Drive Engine Specifications
This engine is an Inline 4 design with 2.7L displacement and a bore x stroke of 94mm x 96.2mm (3.70 x 3.79 in). It uses Electronic Fuel Injection (EFI), a compression ratio of 9.0:1, and runs on 87 octane recommended fuel with a maximum ethanol blend of 10%. Full throttle RPM range is 5,000–6,000 RPM, intake is 16-valve, and the engine carries a C.A.R.B. 3-Star emissions rating. Exhaust routes through the jet nozzle.
Yamaha F150 Jet Drive Electrical, Ignition, and Lubrication
Ignition is handled by a TCI microcomputer system with an LFR5A-11 spark plug, and starting is electric. The alternator delivers 35 amp output at wide-open throttle. Lubrication is a wet sump system using Yamalube 4M recommended engine oil, with an oil capacity of 4.5L / 4.3L. Cooling is thermostatically controlled, and recommended fuel filtration is a Yamaha 10-micron fuel/water separating filter (external).
Yamaha F150 Jet Drive Mounting and Steering
This unit uses direct drive gearing and forward-neutral-reverse gear shift, and fits a 25-inch transom. Maximum steering angle is 35° from center in either direction. Degree of tilt is 70°, and degree of trim ranges from -4° through +16°. Total weight is 225 kg (493 lbs).
| Specification | Detail |
|---|---|
| Weight | 225 kg (493 lbs) |
| Full throttle RPM range | 5000–6000 RPM |
| Fuel induction system | EFI |
| Recommended engine oil | Yamalube 4M |
| Engine type | Inline 4 |
| Displacement | 2.7L |
| Bore x stroke | 94mm x 96.2mm (3.70 x 3.79 in) |
| Prop shaft horsepower | 105 HP at 5500 RPM |
| Alternator output at W.O.T. | 35 Amp |
| Compression ratio | 9.0:1 |
| Recommended fuel | Octane 87 |
| Recommended fuel filtration | Yamaha 10-micron fuel/water separating filter (external) |
| C.A.R.B. rating | 3-Star |
| Exhaust | Through jet nozzle |
| Intake | 16-valve |
| Ignition | TCI microcomputer |
| Spark plug | LFR5A-11 |
| Starting system | Electric |
| Lubrication | Wet sump |
| Engine oil capacity | 4.5L / 4.3L |
| Recommended cooling | Thermostatic control |
| Ethanol blend limit | 10% maximum |
| Gear ratio | Direct Drive |
| Gear shift | Forward, Neutral, Reverse |
| Shaft length | Fits 25″ transom |
| Degree of tilt | 70° |
| Degree of trim | -4° through +16° |
| Mounting centers | N/A |
| Steering angle (maximum) | 35° from center, either direction |
| Warranty | Limited 3-Year Pleasure, 1-Year Commercial |
Contact us today to secure this Yamaha F150 Jet Drive, backed by Yamaha’s limited warranty.
