Yamaha In-Line Four F200 Outboard Motor
$17,160.00
Yamaha F200 for sale, an inline four-cylinder outboard delivering 200 HP at 5,500 RPM at the propeller shaft, with a 2.8L displacement, EFI fuel induction, and available in 20″ or 25″ shaft lengths. Backed by Yamaha’s limited warranty program.
Yamaha F200 for sale, an inline four-cylinder outboard engineered for reliable performance, delivering 200 HP at 5,500 RPM at the propeller shaft.
Yamaha F200 Engine Specifications
This engine is an Inline 4 design with 2.8L displacement and a bore x stroke of 96 x 96.2mm (3.78 x 3.79in). It uses Electronic Fuel Injection (EFI), a compression ratio of 10.3:1, and runs on 89 octane recommended fuel with a maximum ethanol blend of 10%. Full throttle RPM range is 5,000–6,000 RPM, intake is 16-valve, and the engine carries a C.A.R.B. 3-Star emissions rating.
Yamaha F200 Electrical, Ignition, and Lubrication
Ignition is handled by a TCI microcomputer system with an NGK-LFR6A-11 spark plug, and starting is electric. The alternator delivers 50 amp output at wide-open throttle. Lubrication is a wet sump system using Yamalube 4M recommended engine oil, with an oil capacity of 4.5L / 4.3L with or without filter. Cooling is thermostatically controlled, and recommended fuel filtration is a Yamaha 10-micron fuel/water separating filter (external).
Yamaha F200 Shaft, Steering, and Mounting
The F200 is available in 20″ or 25″ shaft lengths, with a gear ratio of 1.86:1 and forward-neutral-reverse gear shift. Maximum steering angle is 30° from center in either direction. Degree of tilt is 70°, degree of trim ranges from -4° through +16°, and mounting centers measure 26 inches. Exhaust routes through the propeller. Weight is 234 kg (516 lbs) for the mechanical version or 238 kg (525 lbs) for the DEC (digital electronic control) version.
| Specification | Detail |
|---|---|
| Weight | Mechanical – 234 kg (516 lbs) / DEC – 238 kg (525 lbs) |
| Full throttle RPM range | 5000–6000 RPM |
| Fuel induction system | EFI |
| Recommended engine oil | Yamalube 4M |
| Engine type | Inline 4 |
| Displacement | 2.8L |
| Bore x stroke | 96 x 96.2mm (3.78 x 3.79in) |
| Prop shaft horsepower | 200 HP at 5500 RPM |
| Alternator output at W.O.T. | 50 Amp |
| Compression ratio | 10.3:1 |
| Recommended fuel | Octane 89 |
| Recommended fuel filtration | Yamaha 10-micron fuel/water separating filter (external) |
| C.A.R.B. rating | 3-Star |
| Exhaust | Through propeller |
| Intake | 16-valve |
| Ignition | TCI microcomputer |
| Spark plug | NGK-LFR6A-11 |
| Starting system | Electric |
| Lubrication | Wet sump |
| Engine oil capacity | 4.5L / 4.3L (with/without filter) |
| Recommended cooling | Thermostatic control |
| Ethanol blend limit | 10% maximum |
| Gear ratio | 1.86:1 |
| Gear shift | Forward, Neutral, Reverse |
| Shaft length | 20″ / 25″ |
| Degree of tilt | 70° |
| Degree of trim | -4° through +16° |
| Mounting centers | 26″ |
| Steering angle (maximum) | 30° from center, either direction |
| Warranty | Limited 3-Year Pleasure, 1-Year Commercial |
Contact us today to secure this Yamaha F200, backed by Yamaha’s limited warranty and available in 20″ or 25″ shaft configurations.
